RPC Deep Dive: Building a Remote Call System from Scratch

Network

23 days ago2325 words·12 min read

What You'll Learn

Understand the core ideas and design motivations behind RPC (Remote Procedure Call)
Build a complete RPC system in Node.js, starting from raw TCP and iteratively improving it
Master serialization, communication protocols, error handling, and other key RPC concepts
Get hands-on with gRPC and Protocol Buffers for production-grade RPC

Prerequisites

Basic understanding of the client-server model
Some Node.js experience (familiarity with the net module helps, but not required)
A general grasp of the earlier articles in this series, especially TCP

Refer to the previous article in this series:

Starting From a Real Scenario

Imagine you're building an e-commerce system. The Order service needs to call the Inventory service to check whether a product is in stock. Your first instinct might be: "I'll just use fetch('/api/check-stock') and call it a day."

That works. But then the problems start creeping in:

Every call requires you to write URL, method, headers, body serialization... boilerplate drowns the business logic.
The API contract between services lives in "tribal knowledge." One day the Inventory team renames a field, and your code silently breaks.
HTTP/JSON is universal, but under high-throughput internal calls, the parsing overhead adds up.

RPC was designed to solve exactly these problems. The vision: calling a function on a remote service should feel as natural as calling add(1, 2) right in your own process. No URLs, no manual serialization, and the interface definition is enforced by an IDL (Interface Definition Language).

What Is RPC?

From Local Calls to Remote Calls

Let's start with what we all know — a local function call:

function add(a, b) {
  return a + b;
}

const result = add(3, 5); // Direct call — everything in the same process
console.log(result);       // 8

Everything here is "local." Function definition, argument passing, return value — all within one process. The CPU does a call/ret instruction pair. Latency is in microseconds.

But what if add runs on a different server?

RPC (Remote Procedure Call) aims to make this cross-network function call look and feel, at the code level, no different from the local version.

A Real-World Analogy

Local call: You turn to your colleague sitting next to you: "Hey, can you grab me a coffee?" They get up, grab it, hand it to you. Ten seconds, done.
Remote call: You're in the Beijing office and Slack a colleague in Shenzhen: "Can you pull up Q2 sales figures for the South China region?" They look it up and reply. Same logic, but the message traveled across the network.

An RPC framework handles the "send the message, wait for the reply" plumbing so you can write getQ2Sales("south-china") and not think about crafting HTTP requests.

Building the Simplest Possible RPC

Now that we understand the why, let's build the what. We'll start with the most bare-bones version — a TCP-based toy RPC system.

For simplicity, we assume each TCP packet carries exactly one complete JSON request. In real-world scenarios, large messages may be split across multiple packets, which requires more sophisticated framing — something we'll handle in the improved version.

Server

// server.js
import net from "net";

// Our "remote" methods
const methods = {
  add: (a, b) => a + b,
  greet: (name) => `Hello, ${name}!`,
};

const server = net.createServer((socket) => {
  console.log("Client connected");

  socket.on("data", (data) => {
    try {
      // Parse the incoming request
      const request = JSON.parse(data.toString());
      console.log("Received request:", request);

      // Execute the target method
      const result = methods[request.method](...request.params);

      // Send back the result
      const response = JSON.stringify({
        result,
        id: request.id,
      });
      socket.write(response);
    } catch (error) {
      console.error("Error processing request:", error);
    }
  });
});

server.listen(3000, () => {
  console.log("RPC service running on port 3000");
});

Client

// client.js
import net from "net";

class SimpleRPCClient {
  constructor(port = 3000, host = "localhost") {
    this.port = port;
    this.host = host;
    this.requestId = 0;
  }

  call(method, ...params) {
    return new Promise((resolve, reject) => {
      const socket = new net.Socket();
      const currentId = ++this.requestId;

      const request = JSON.stringify({
        method,
        params,
        id: currentId,
      });

      socket.connect(this.port, this.host, () => {
        socket.write(request);
      });

      socket.on("data", (data) => {
        const response = JSON.parse(data.toString());
        if (response.id === currentId) {
          resolve(response.result);
          socket.end();
        }
      });

      socket.on("error", (err) => reject(err));
    });
  }
}

// Usage
(async () => {
  const client = new SimpleRPCClient();

  try {
    const sum = await client.call("add", 5, 3);
    console.log("5 + 3 =", sum); // 8

    const greeting = await client.call("greet", "RPC Beginner");
    console.log(greeting);       // Hello, RPC Beginner!
  } catch (err) {
    console.error("Call failed:", err);
  }
})();

Running It

bash

# Start the server first
node server.js

# Then run the client
node client.js

This tiny example may look simple, but it already contains every essential piece of RPC. Let's break it down.

Core RPC Concepts

Serialization & Deserialization

For a function call to travel across a network, arguments and return values must become byte streams.

Serialization: Converting in-memory data structures into a transmittable format (JSON string, binary, etc.)
Deserialization: Reconstructing received bytes back into in-memory data structures

In our example:

// Serialization: in-memory object → JSON string
const request = JSON.stringify({ method: "add", params: [1, 2] });

// Deserialization: JSON string → in-memory object
const data = JSON.parse(request);

JSON is human-friendly but verbose and slow to parse. Production systems typically choose more efficient serialization schemes like Protocol Buffers or MessagePack — we'll get to those shortly.

Communication Protocol

We used Node.js's net module to establish a TCP connection. In practice, RPC can ride on various protocols:

Protocol	Characteristics	Best For
TCP	Performant, binary transport	Internal microservice calls
HTTP/2	Universal, firewall-friendly	Cross-network, browser-compatible
WebSocket	Full-duplex, native browser support	Browser ↔ server real-time

The Request-Response Model

Every RPC call is an explicit request-response pair:

// Request format
{
  method: "add",         // Which method to call
  params: [1, 2],        // Arguments
  id: 1                  // Unique ID — used to match the response
}

// Response format
{
  result: 3,             // Return value
  id: 1                  // Matches the corresponding request ID
}

The id field is crucial: a single TCP connection may carry multiple concurrent requests (pipelining). The id lets the client correlate each response with its originating request.

Improving the RPC Implementation

The first version has several issues:

No error handling — if the server throws, the client just hangs
No timeout — a stuck request blocks forever
Assumes one packet = one complete message — TCP is a stream; large messages arrive in chunks

Let's fix them one by one.

Improved Server

// better-server.js
import net from "net";

const methods = {
  add: (a, b) => a + b,
  greet: (name) => {
    if (!name) throw new Error("Name cannot be empty");
    return `Hello, ${name}!`;
  },
};

const server = net.createServer((socket) => {
  console.log("Client connected");

  socket.on("data", (data) => {
    try {
      const request = JSON.parse(data.toString());
      console.log("Received request:", request);

      if (!methods[request.method]) {
        throw new Error(`Method "${request.method}" does not exist`);
      }

      const result = methods[request.method](...request.params);

      socket.write(
        JSON.stringify({
          result,
          id: request.id,
          error: null,
        })
      );
    } catch (error) {
      socket.write(
        JSON.stringify({
          result: null,
          id: request?.id ?? null,
          error: error.message,
        })
      );
    }
  });
});

server.listen(3000, () => {
  console.log("Improved RPC service running on port 3000");
});

Key changes:

Error field: The response now includes an error field. On success, error: null; on failure, it carries the error message. No more guesswork for the client.
Method validation: Calling a non-existent method now produces a clear error instead of silently crashing.

Improved Client

// better-client.js
import net from "net";

class BetterRPCClient {
  constructor(port = 3000, host = "localhost") {
    this.port = port;
    this.host = host;
    this.requestId = 0;
  }

  async call(method, ...params) {
    const socket = new net.Socket();
    const currentId = ++this.requestId;

    const request = JSON.stringify({
      method,
      params,
      id: currentId,
    });

    return new Promise((resolve, reject) => {
      let responseData = "";

      socket.connect(this.port, this.host, () => {
        socket.write(request);
      });

      socket.on("data", (data) => {
        responseData += data.toString();

        try {
          const response = JSON.parse(responseData);
          if (response.id === currentId) {
            if (response.error) {
              reject(new Error(response.error));
            } else {
              resolve(response.result);
            }
            socket.end();
          }
        } catch {
          // Incomplete data — keep buffering
        }
      });

      socket.on("error", (err) => reject(err));

      socket.on("timeout", () => {
        reject(new Error("Request timed out"));
        socket.end();
      });

      socket.setTimeout(5000); // 5-second timeout
    });
  }
}

// Usage
(async () => {
  const client = new BetterRPCClient();

  try {
    console.log("1 + 2 =", await client.call("add", 1, 2));
  } catch (err) {
    console.error("Call error:", err.message);
  }

  // Call a non-existent method
  try {
    await client.call("nonexistent");
  } catch (err) {
    console.error("Expected error:", err.message);
  }

  // Trigger parameter validation
  try {
    await client.call("greet"); // No name provided
  } catch (err) {
    console.error("Validation error:", err.message);
  }
})();

Three key improvements:

Error propagation: The server's error field becomes a client-side reject, so callers can use try/catch.
Timeout: socket.setTimeout(5000) prevents indefinite hangs.
Buffering: responseData += data accumulates chunks until a complete JSON object is assembled — solving the TCP stream-framing problem.

Going Production-Grade: gRPC

Building RPC from scratch teaches the principles, but in real projects you'll use a mature framework. gRPC is Google's open-source modern RPC framework, built on HTTP/2 and Protocol Buffers.

Why gRPC?

Aspect	Hand-rolled RPC (JSON/TCP)	gRPC
Serialization	JSON (text, verbose)	Protocol Buffers (binary, compact)
Transport	Raw TCP	HTTP/2 (multiplexing, flow control)
Interface definition	Verbal agreement	`.proto` file (strongly typed IDL)
Code generation	None	Auto-generated client/server stubs
Multi-language	Hand-coded per language	Officially supports 10+ languages

Getting Started with gRPC

Install dependencies:

bash

npm install @grpc/grpc-js @grpc/proto-loader

Define the service interface — create calculator.proto:

protobuf

syntax = "proto3";

service Calculator {
  rpc Add (Numbers) returns (Result);
  rpc Multiply (Numbers) returns (Result);
}

message Numbers {
  double a = 1;
  double b = 2;
}

message Result {
  double value = 1;
}

This .proto file is gRPC's "contract" — server and client share a single definition. Field types and numbers are enforced by Protocol Buffers, eliminating "tribal knowledge" drift.

Implement the server:

// grpc-server.js
import grpc from "@grpc/grpc-js";
import protoLoader from "@grpc/proto-loader";

const packageDefinition = protoLoader.loadSync("calculator.proto");
const calculatorProto = grpc.loadPackageDefinition(packageDefinition);

const server = new grpc.Server();

const calculator = {
  add: (call, callback) => {
    const { a, b } = call.request;
    callback(null, { value: a + b });
  },
  multiply: (call, callback) => {
    const { a, b } = call.request;
    callback(null, { value: a * b });
  },
};

server.addService(calculatorProto.Calculator.service, calculator);

server.bindAsync(
  "0.0.0.0:50051",
  grpc.ServerCredentials.createInsecure(),
  (err, port) => {
    if (err) {
      console.error(err);
      return;
    }
    server.start();
    console.log(`gRPC service running on port ${port}`);
  }
);

Implement the client:

// grpc-client.js
import grpc from "@grpc/grpc-js";
import protoLoader from "@grpc/proto-loader";

const packageDefinition = protoLoader.loadSync("calculator.proto");
const calculatorProto = grpc.loadPackageDefinition(packageDefinition);

const client = new calculatorProto.Calculator(
  "localhost:50051",
  grpc.credentials.createInsecure()
);

// Call the remote Add method
client.add({ a: 10, b: 20 }, (err, response) => {
  if (err) {
    console.error("Error:", err.message);
    return;
  }
  console.log("10 + 20 =", response.value); // 30
});

// Call the remote Multiply method
client.multiply({ a: 7, b: 8 }, (err, response) => {
  if (err) {
    console.error("Error:", err.message);
    return;
  }
  console.log("7 * 8 =", response.value); // 56
});

Note: a gRPC client call no longer looks like client.add(10, 20) — it passes a request object and a callback (or a Promise in async-capable gRPC versions). While the syntax doesn't perfectly mimic a local call, the .proto file guarantees type safety and interface consistency — that's the real value of RPC in production.

Hands-On Practice

Basic Exercises

Run the SimpleRPC example above and successfully call both the add and greet remote methods.
Add a multiply method to the methods object and verify the client can call it.

Advanced Challenges

Improve BetterRPCClient with connection reuse: instead of creating a new TCP connection per call, maintain a persistent socket with a request queue. Hint: use one long-lived socket and correlate responses by request ID.
Run the gRPC example, then define a subtract RPC method in the .proto file and implement it on both sides.

Summary & Key Takeaways

RPC's core goal: make calling a remote function feel as natural as calling a local one.
Three essential ingredients: serialization (how data is encoded), communication protocol (what channel it travels over), and interface definition (which methods both sides agree on).
Build from scratch to understand the principles; use gRPC in production to get serialization optimization, multiplexing, code generation, and more for free.
Protocol Buffers' .proto files serve as both interface documentation and type enforcement, eliminating the friction of "verbal contracts" between teams.

Keywords: RPC, Remote Procedure Call, gRPC, Protocol Buffers, serialization, TCP, IDL, microservice communication
