Binary in the Browser: Understanding ArrayBuffer, TypedArray, and DataView

JS Syntax

Binary

2025 Apr 13965 words·5 min read

In modern computer science, binary data is the foundation of information storage and transmission. Whether it's files, network protocols, or multimedia data like images and audio, everything is ultimately stored and processed in binary form. To better understand ArrayBuffer, TypedArray, and DataView in JavaScript, we first need to grasp some fundamental binary concepts, including bit, Byte, and Hexadecimal.

Binary Basics

Bit

A bit is the smallest unit of data in a computer, representing a binary digit that can be either 0 or 1. For example:

0 represents "off" or "false."
1 represents "on" or "true."

Multiple bits can be combined to represent more complex data. For instance, 2 bits can represent 4 states (00, 01, 10, 11), 3 bits can represent 8 states, and so on.

Byte

A Byte is a common unit of data in computers, consisting of 8 bits. One Byte can represent 256 different states (from 00000000 to 11111111, i.e., 0 to 255).

1 Byte = 8 bits
1 KB (Kilobyte) = 1024 Bytes
1 MB (Megabyte) = 1024 KB
1 GB (Gigabyte) = 1024 MB

Hexadecimal

Hexadecimal is a concise way to represent binary data. It uses 16 symbols (0-9 and A-F) to represent the value of a Byte. For example:

Binary 00000000 = Hexadecimal 0x00 = Decimal 0
Binary 11111111 = Hexadecimal 0xFF = Decimal 255
Binary 10101010 = Hexadecimal 0xAA = Decimal 170

Hexadecimal is advantageous because it provides a more compact representation of binary data while remaining human-readable.

Storing and Reading Binary Data

In computers, binary data is typically stored and read in Bytes. For example, a 16-bit integer (2 Bytes) can be stored as two consecutive Bytes, while a 32-bit floating-point number (4 Bytes) can be stored as four consecutive Bytes.

Endianness

When storing multi-byte data, computer systems write the data into memory in a specific order, known as Endianness:

Big-Endian: The high-order byte is stored at the lower address, and the low-order byte is stored at the higher address.
Little-Endian: The low-order byte is stored at the lower address, and the high-order byte is stored at the higher address.

For example, the 16-bit integer 0x1234 is stored as follows:

Big-Endian: 0x12 (high-order byte) is stored at the lower address, and 0x34 (low-order byte) is stored at the higher address.
Little-Endian: 0x34 (low-order byte) is stored at the lower address, and 0x12 (high-order byte) is stored at the higher address.

Handling Binary Data in JavaScript

JavaScript provides tools like ArrayBuffer, TypedArray, and DataView to efficiently handle binary data.

ArrayBuffer: A Container for Binary Data

ArrayBuffer is an object in JavaScript used to represent a contiguous block of memory. It stores raw binary data but does not directly manipulate it. Instead, ArrayBuffer acts as a "container," and we need other views (like TypedArray or DataView) to access and manipulate the data.

javascript

const buffer = new ArrayBuffer(16); // Create a 16-byte buffer

TypedArray: Typed Array Views

TypedArray is a set of array views that allow us to access ArrayBuffer data using specific data types (e.g., Int8, Uint16, Float32, etc.). Common TypedArray types include:

Int8Array: 8-bit signed integer
Uint8Array: 8-bit unsigned integer
Int16Array: 16-bit signed integer
Uint16Array: 16-bit unsigned integer
Float32Array: 32-bit floating-point number
Float64Array: 64-bit floating-point number

javascript

const buffer = new ArrayBuffer(16);
const int16Array = new Int16Array(buffer); // Access buffer as 16-bit signed integers
int16Array[0] = 0x1234; // Write data
console.log(int16Array[0].toString(16)); // Read data, outputs "1234"

DataView: A Flexible Data View

DataView is another way to access ArrayBuffer, providing flexible methods to read and write different types of data.

Unlike TypedArray, DataView allows us to read or write various data types in the same ArrayBuffer without creating multiple views.

javascript

const buffer = new ArrayBuffer(16);
const view = new DataView(buffer);

view.setInt16(0, 0x1234, true); // Write a 16-bit signed integer at byte 0 (Little-Endian)
view.setFloat32(4, 3.14, true); // Write a 32-bit floating-point number at byte 4 (Little-Endian)

console.log(view.getInt16(0, true).toString(16)); // Read data at byte 0, outputs "1234"
console.log(view.getFloat32(4, true)); // Read data at byte 4, outputs 3.14

Writing an Endianness Detection Function

Now, let's demonstrate the practical use of ArrayBuffer, TypedArray, and DataView by writing a function to detect the system's endianness.

The function writes a known value to an ArrayBuffer and then reads its bytes to determine the endianness.

Implementing the Endianness Detection Function

javascript

function detectEndianness() {
    // Create a 2-byte ArrayBuffer
    const buffer = new ArrayBuffer(2);
    const view = new DataView(buffer);

    // Write a 16-bit integer 0x1234
    view.setUint16(0, 0x1234, true); // Use Little-Endian

    // Read the first byte
    const firstByte = view.getUint8(0);

    // Determine endianness
    if (firstByte === 0x34) {
        return 'Little-Endian'; // Low-order byte at lower address
    } else if (firstByte === 0x12) {
        return 'Big-Endian'; // High-order byte at lower address
    } else {
        return 'Unknown';
    }
}

console.log(detectEndianness()); // Outputs the system's endianness

Explanation

Write Data: We use DataView.setUint16 to write 0x1234 into the ArrayBuffer, specifying Little-Endian (true). If the system is Little-Endian, 0x34 will be stored at the lower address; if it's Big-Endian, 0x12 will be stored at the lower address.
Read Data: We use DataView.getUint8 to read the first byte. If the value is 0x34, the system is Little-Endian; if it's 0x12, the system is Big-Endian.
Return Result: Based on the read value, the function returns the system's endianness.

Conclusion

Binary data is the foundation of computer science, and JavaScript's ArrayBuffer, TypedArray, and DataView provide powerful tools for handling binary data.

By mastering binary basics, we can better understand how these tools work and apply them effectively in real-world development.
