Build a Database from Zero (Part 8): A Page — Reading by the Chunk, Not by the Row

Database

PostgreSQL

Build from Zero

2 hours ago1235 words·7 min read

What You'll Get Out of This

See the inside of a page — the chunk you invented in Part 7 — and why a row lives in it with a "directory";
Understand why a database reads by page, not by row, and why "one row per read" would be a disaster;
Explain, by your own reasoning, why page size (8KB in PostgreSQL) matters so much.

Before We Start

Know Part 7: a heap file is a sequence of fixed-size chunks = pages;
Know Part 6: a row's address (TID) is "page + slot."

Part 7 Left You With a Chunk of Bytes

Last part you made a file out of pages. But there's a nagging detail: a page is just a pile of bytes. So how does a database find a specific row inside those bytes? And why would it ever want to fetch a whole page to read one row?

Let's answer the second question first, because it's the more famous one.

Question 1: Why Read by Page, Not by Row?

Imagine you could ask the disk for "just row 42, 60 bytes." Sounds efficient. But here's the cost nobody shows you: the disk is slow to get started, not slow per byte.

Think of a disk (or an SSD): before it delivers a single byte, it must move a head or locate a cell — a big up-front cost called seek. If you read one 60-byte row and pay a full seek, you've spent a lot of effort for almost nothing.

The database's answer (and the operating system's too): read a bigger chunk at once, and use every useful thing inside it. If a page is 8KB, one seek buys you ~8000 bytes — and the row you wanted is somewhere inside. Reading "one page" is almost as cheap as reading "one row," but you get a hundred times more data.

You met this idea in Part 1 as the book analogy — you don't read "one character per page-turn," you read a page. Now it's literal.

Question 2: So How Do We Find a Row Inside a Page?

Now the harder part: a page is a jumble of rows, and rows have variable lengths. If you just had a stream of bytes, finding the 3rd row means counting byte by byte — which is O(rows) per lookup. Awful.

The fix is a directory. Put a small list at the front of the page: for each row, record its offset (where it starts) and its length. Then the data can pile up from the back. Here's the shape:

txt

┌────────────────────────────── Page (a few KB) ──────────────────────────────┐
│  header  │  dir entry 1  │  dir 2  │  dir 3  │  ...  free space ...  row3 │ row1 │ row2 │
│  (page   │  → offset,len │ →...   │ →...    │                            │      │      │
│   info)  │                                            ↑ rows grow from the back │
└──────────────────────────────────────────────────────────────────────────────┘

The directions "from the back" and "from the front" meet in the middle, so the page uses its space efficiently. Let's implement a tiny page that finds a row by going through the directory:

const PAGE_SIZE = 1024;

// a "page" = a header + a directory + row data
function createPage() {
  return {
    header: { pageId: 0, freeStart: 0, freeEnd: PAGE_SIZE },
    dir: [],           // entries: { offset, length }
    data: new Uint8Array(PAGE_SIZE)
  };
}

// write a row into the page, add a dir entry, return its "slot"
function appendRow(page, bytes) {
  const length = bytes.length;
  page.data.set(bytes, page.header.freeEnd - length);
  page.header.freeEnd -= length;
  page.dir.push({ offset: page.header.freeEnd, length });
  return page.dir.length - 1;   // the slot = position in the directory
}

// read the row at "slot" via the directory
function readRow(page, slot) {
  const entry = page.dir[slot];
  return page.data.subarray(entry.offset, entry.offset + entry.length);
}

Now you see the structure clearly: the directory is the page's "address plate," and a TID's "slot" is just an index into that directory. That's exactly the "directories (item pointers)" you've heard about.

And look what unifies with Part 6: a row's TID = (page, slot). The page tells you which chunk; the slot tells you which directory entry — and the directory entry says where in the page the bytes actually are. The whole addressing chain is now visible and built by you:

txt

TID (page, slot)  →  find the page  →  dir[slot] gives (offset, length)  →  read the bytes

Question 3: Why 8KB? You Can Puzzle It Out

Now the famous "8KB." Why not 512 bytes? Why not 1MB? You've seen the two opposing pulls, so you can reason through the balance yourself:

Bigger pages → fewer seeks per amount of data (good for big sequential scans).
Smaller pages → less wasted data per read when you only wanted one row (good for random, keyed lookups).

If pages are huge, a point query (WHERE id = 42) drags in a lot of rows you didn't want. If pages are tiny, a large scan does a lot of seeks. The sweet spot — a few KB — balances these. PostgreSQL chose 8KB; MySQL InnoDB chose 16KB. Neither is "right" — they're a judgment call shaped by the workload.

Remember the whole point: you don't pay for the row you want; you pay for the page that contains it. So page size is a bet on "how often you want the neighbors."

Hands-On Practice

Build the directory: use appendRow/readRow to add rows of different lengths and confirm readRow(2) returns the right bytes — the directory is doing the work.
Show why "read one row" is a bad idea: log that every readRow actually touches an entire page, not just one row. Now imagine a full table scan of 1M rows — how many pages do you hit?
Tune the page size: change PAGE_SIZE and reason out which workload (many tiny keyed lookups vs one big scan) would prefer bigger vs smaller.

Summary and Keywords

The disk is slow to start (seek), not per byte — so a database reads one page at a time and uses all the useful rows in it;
A page has a directory at the front (offset + length per row) and rows piled from the back; the directory is the page's "address plate";
A row's TID (page, slot) = "which chunk" + "which directory entry" — the full addressing chain;
Page size is a bet: bigger favors big scans, smaller favors point lookups; 8KB (PG) vs 16KB (InnoDB) are judgment calls.

Keywords: page、seek、directory / item pointers、offset、slot、TID、page size、point vs scan

What's Next

You can now read one page from disk, and find a row inside it. But notice the punchline you've been building toward: a query might need a page that's already been read once by an earlier query. Reading disk is expensive — so wouldn't it be smart to keep the most-recently-read pages in memory, instead of going back to disk every time?

That's Part 9: a page cache — the buffer pool. And it explains one of the most comforting observations in all of databases: the same query is slow first, fast second. You're about to implement the reason why.
