You Use Git Every Day, But Do You Really Understand It? — Completely Understand Git from Its Underlying Data Structures

You've been using Git for years. You can handle commit, push, merge, and rebase easily. But if someone asks you:

• "Why are Git branches so fast?"
• "What exactly is stored in the .git folder?"
• "Where do the files come from when you do git checkout?"

You might hesitate.

This article aims to break down and thoroughly explain Git's underlying workings. You don't need to have read Git's source code. But after reading, you'll find that Git's every action makes perfect, "obvious" sense.

Most people understand Git as a "version control tool." That's correct, but that's the high-level view.

From the low level, Git is a content-addressable key-value storage system.

What does that mean?

You give Git some data. Git computes a SHA-1 hash for it, producing a 40-character hexadecimal string as the key. Then it stores the data. Later, you can use that key to retrieve the original data.

It's like a massive HashMap<String, byte[]>. The key is the hash of the content, and the value is the compressed content itself.

You can verify this yourself:

This is the entire foundation of Git. All the concepts that follow—files, directories, commits, branches—are built on top of this key-value store.

Inside the .git/objects/ directory, there are only 4 types of objects. Understand them, and you understand 90% of Git.

A Blob (Binary Large Object) stores pure file content. It does not contain any metadata like the filename, path, or permissions.

A key design point: If two files have identical content, no matter their names or directories, Git stores only one blob.

This means if you copy and paste the same config file 10 times in your project, Git's storage increases by only one copy.

Since blobs don't have filenames, where are filenames stored? The answer is the tree object.

A Tree is a "directory listing" that records:

• The type of each entry (blob or sub-tree)
• File permissions (100644 for normal files, 100755 for executables, 040000 for directories)
• The hash of the corresponding object
• The file/directory name

Output looks like:

src is a sub-tree. It points to its own blobs and trees. This is a recursive structure, exactly like a filesystem directory tree.

Visualized:

The Commit object is the "glue" that ties everything together. It records:

Each commit points to a complete tree. This means each commit is a complete snapshot of the project at that moment.

This differs from many people's intuition—you might think commits store "what changed" (diff), but actually, commits store "what the whole project looked like" (snapshot).

Then how does git diff work? The answer: It dynamically compares two tree objects, rather than storing differences in advance.

An annotated tag is a separate object pointing to a commit with extra info (tagger name, message, signature, etc.). A lightweight tag is just a reference, not an object. Not commonly used in daily development, so we won't elaborate here.

Now we have all the building blocks. Let's see how they assemble:

The entire Git repository is a Directed Acyclic Graph (DAG):

• HEAD → current branch → latest commit
• Commit → parent commit (forms history chain) + root tree (complete snapshot)
• Tree → sub-trees + blobs (directory structure)
• Blob → file content

This might be one of Git's most elegant designs.

A branch is simply a text file, containing a 40-character commit hash.

Therefore:

This is why Git branch operations are instantaneous—you're just reading/writing a tiny file of a few dozen bytes, not copying an entire directory like in SVN.

Many know Git has three areas: "Working Directory → Staging Area → Repository." But they're unclear about what the Staging Area actually is.

The Staging Area is the binary file .git/index. It's essentially a flattened tree, recording:

When you execute git add file.ts:

1. Git hashes the content of file.ts and stores it as a blob object.
2. Updates .git/index, changing the blob hash for file.ts to the new one.

When you execute git commit:

1. Git converts the contents of .git/index into tree objects (creating sub-trees recursively).
2. Creates a commit object pointing to this tree.
3. Updates the reference of the current branch.

Therefore, the Staging Area is the "draft for the next commit."

If every file in every version were stored as a full blob, wouldn't the repository explode?

Git has a background optimization called packfile. When the number of objects reaches a threshold (or you run git gc), Git will:

1. Find blobs with similar content (e.g., different versions of the same file).
2. Store only the latest version in full. Older versions are stored as delta (differences) from the newer version.
3. Pack all objects into a single .pack file, accompanied by an .idx index file.

This is why Git repositories are often much smaller than you'd expect—logically, each commit is a full snapshot, but physically, only the differences of similar content are stored.

Note: This is a pure storage optimization; it doesn't affect the high-level semantics. From the API perspective, you always get the complete blob content; delta expansion is transparent.

Now that you have the low-level knowledge, let's reinterpret some daily operations:

1. Download all objects (blobs, trees, commits) from the remote repository to the local .git/objects/.
2. Download all references (branches, tags) to .git/refs/.
3. Checkout the default branch: From commit → tree → blob, "unpack" files into the working directory.

A Fast-forward merge only needs to move the main reference from C to E. No new objects are created; only a pointer is changed.

Git finds the common ancestor B, compares the tree differences between B→F and B→E, merges them, and creates a new tree and a new commit (with two parents).

Rebase doesn't "move" commits; it recreates commits. Because a commit's hash depends on its parent, tree, timestamp, etc. If the parent changes, the hash changes. So the rebased commits are entirely new objects. The old commits remain in .git/objects/ (until garbage collected).

Stash essentially creates a special commit (not attached to any branch), with its reference stored in .git/refs/stash. git stash pop applies that commit's content to the working directory and then deletes the reference.

Worktree doesn't copy the .git directory. Instead, it creates a .git file (not a directory) in the new directory, pointing to the main repo's .git:

Then, from the shared .git/objects/, following the target branch's commit → tree → blob, it "unpacks" files into the new directory. Objects are shared; files are regenerated.

Don't just read; try it. Open a terminal and run these in any Git repository:

After these 7 steps, you'll have a muscle-memory level understanding of Git's internal structure.

Git's design philosophy: The bottom layer is minimalist (4 object types + references), the upper layers are flexible (all advanced features are operations on these basic structures).

Once you understand this layer, commands like merge, rebase, cherry-pick, reflog, and worktree are no longer incantations to memorize, but natural operations on a data structure. You can even predict how the .git directory will change after a command executes—that's what it truly means to "understand" Git.
